YK Swing Granulator
The mixed material is processed into particles of the desired size, or the agglomerated material is broken down into small particles; this machine is suitable for granulation in the pharmaceutical, ch···
Category:Granulation equipment
Product Inquiry: 13961458166
- Product Details
- Photo Collection
Working principle
Make the stirred materials into particles of the required size, or beat the agglomerated materials into small particles.
Adaptable materials
This machine is suitable for granulation in pharmaceutical, chemical, food, solid beverage and other industries.
Technical specifications
| Model | YK160 | YK320 |
| Production capacity | 50-200 kg/h | 50-400 kg/h |
| Motor power | 2.2kw | 7.5kw |
| Drum speed | 65rpm | 65rpm |
| Swing angle | 360o | 360o |
| Drum diameter | Φ160mm | Φ320mm |
| Weight | 450kg | 750kg |
| Dimensions | 1000×800×1300m | 1500×1200×1500m |
