Working principle
The powder material and adhesive are thoroughly mixed into a wet soft material in a cylindrical container through a bottom mixing slurry, and then cut into uniform wet particles by a high-speed grinding blade placed on the side.
Performance characteristics
◎This machine adopts a horizontal cylindrical structure with a reasonable structure.
◎Inflatable sealed drive shaft, can be switched to water during cleaning.
◎Fluidized granulation results in approximately spherical particles with good flowability.
◎Reduce adhesive by 25% compared to traditional processes and shorten drying time.
◎Each batch is only dry mixed for 2 minutes and pelletized for 1-4 minutes, which increases efficiency by 4-5 times compared to traditional processes.
◎Completed in the same closed container, dry mixing wet mixing granulation process is shortened.
◎The entire operation has strict safety protection measures.
◎It can be made into a jacket type according to user requirements.
Technical specifications:
| Model | A | B | C×D | E | F |
| 50 | 320 | 950 | 1250×800 | 970 | 1650 |
| 150 | 420 | 1000 | 1350×800 | 1050 | 1750 |
| 200 | 500 | 1100 | 1650×940 | 1450 | 2050 |
| 250 | 500 | 1160 | 1650×940 | 1400 | 2260 |
| 300 | 550 | 1200 | 1700×1000 | 1400 | 2310 |
| 400 | 670 | 1300 | 1860×1100 | 1550 | 2410 |
| 600 | 750 | 1500 | 2000×1230 | 1750 | 2610 |
| Name | Model | ||||||
| 50 | 150 | 200 | 250 | 300 | 400 | 600 | |
| Volume(L) | 50 | 150 | 200 | 250 | 300 | 400 | 600 |
| Production(kg/batch) | 15 | 50 | 80 | 100 | 130 | 200 | 280 |
| Mixing speed(r.p.m) | 200/400 | 180/270 | 180/270 | 180/270 | 140/220 | 106/155 | 80/120 |
| Hybrid power(kw) | 4/5.5 | 6.5/8 | 9/11 | 9/11 | 13/16 | 18.5/22 | 22/30 |
| Cutting speed(r.p.m) | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 | 1500/3000 |
| Cut power(kw) | 1.3/1.8 | 2.4/3 | 4.5/5.5 | 4.5/5.5 | 4.5/5.5 | 6.5/8 | 9/11 |
| Compressed air consumption(m3/min) | 0.6 | 0.9 | 0.9 | 0.9 | 1.1 | 1.5 | 1.8 |
| Weight(kg) | 500 | 800 | 1000 | 1300 | 1800 | 2200 | 2600 |
