Product Usage
This machine is suitable for industries such as pharmaceuticals, chemicals, metallurgy, food, and construction. Processing hard and difficult to crush materials, including plastic, copper wire, Chinese herbal medicine, rubber, etc. It can also be used as a supporting equipment for the pre-processing of micro crushers and ultrafine crushers.
Working principle
The material is fed into the crushing chamber from the feeding hopper, and through the impact of the blade and the blade holder, the rotating blade and the fixed blade are simultaneously sheared and crushed. Due to the centrifugal force of rotation, the material automatically flows out from the outlet.
Technical Parameters
| Model | CSJ-250 | CSJ-500 |
| Feed particle size | ≤100 | ≤100 |
| Discharge particles | 0.5-20 | 0.5-20 |
| Spindle speed | 940 | 1000 |
| Power | 4 | 11 |
| Yield | 50-300 | 80-800 |
| Overall dimensions | 860×650×1020 | 1120×1060×1050 |
